Power Factor

OK power factor can be described in terms of harmonics but it is worthy of a few words of its own.

Power Factor is banded about on a daily basis and generally held to be commonly and widely understood, but is it?

Power Factor only occurs in AC circuits and has no units, being described as a ratio - a number between minus 1 and plus 1. That’s right minus 1, how is it so we hear you say. Well if the load is regenerating the power factor can go into negative territory.

In all honesty and for practical purposes this is an event that most will not need to consider, but it highlights the subtlety of the topic, there is much more to it than meets the eye.

For example a commonly held misconception is low Power Factor requires more power to do the same work. Fact is this is not so – go back to your basic electro technology or pick up an appropriate physics book and see for yourself, remember Power is watts and work is watts, not KVA!

Depending on just how low the offending Power Factor is it may seem that it takes more power to do the same work as you may be penalised for by your electricity supplier for poor Power Factor, but not all users fall into this category.

Yes, there will be circumstances where the penalty for poor Power Factor is the need for larger mains wiring or heating effect on equipment but again be careful to examine the whole story.

If you are not on a KVA tariff you are not being penalised. Remember it’s your money and you may not need to spend it.

There are two different ways to calculate the Power Factor being: Displacement Power Factor and Apparent Power Factor. Both will produce identical results for sinusoidal voltage and current waveforms where there is no distortion as occurs with DOL operation of transformers, induction motors, high intensity discharge lighting and the like.

In our modern world, many everyday devices from computer power supplies, fluorescent lighting, elevators, escalators, variable speed drives, electric trains, etc. have power circuitry that distorts the sinusoidal waveforms. and in these instances Displacement Power Factor – which is the Power Factor due to the phase shift between voltage and current at the fundamental line frequency – is no longer appropriate and must be now expressed as the Apparent Power Factor, which takes into account the resultant harmonic distortion.

Think of a variable frequency inverter driving an induction motor. Strictly speaking, as the VSD does not cause any significant displacement of the voltage and current waveforms on its input it could be thought to have a displacement power factor of close to unity.

All very nice, and depending on the type of metering it may even appear as unity Power Factor, but given the distortion present on the input to the drive to the rectifiers in circuit the correct representation of the Power Factor should be the Apparent Power Factor.So should we now correct the building Power Factor using Harmonic Filtering or by conventional powerfactor correction capacitors? A very good question.

Still confused? Give the friendly engineers at Zener a ring or send us an email. We don’t sell power factor correction so we don’t have a conflict of interest, but we do endorse good housekeeping when it comes to Power Factor so rest assured we would be happy to help.
